Electrical Control Panel

Electrical Control Panel Specification

Ambient Temperature
-10C to +55C

Suitable For
Industrial Automation, Lighting, Distribution, Process Control

Dimension (L*W*H)
Custom/Standard as per requirement (Sample: 1000x800x300 mm)

Capacity
Up to 1000 Amps (customizable)

Power
Up to 750 kW (customizable)

Product Type
Electrical Control Panel

Material
Mild Steel

Input Voltage
415 V AC

Output Voltage
415 V AC

Usage
Industrial/Commercial Power Distribution

Rated Frequency
50 Hz

Voltage Range
380-440 V

Size
Custom/Standard

Weight
Approx. 40-120 kg (varies with panel size)

Operating Humidity
Up to 95% RH (non-condensing)

Short Circuit Withstand
Up to 50 kA (as design)

Wiring Type
Internal PVC Insulated Copper

Control Device Type
MCB, MCCB, Contactor, Relay (as per requirement)

Bus Bar Material
Electrolytic Grade Copper / Aluminium

Enclosure Protection
IP42 / IP54 (optional)

Door Type
Single/Double Door

Panel Type
Power Control Center (PCC), Motor Control Center (MCC), Distribution

Color Finish
Siemens Grey Powder Coated

Mounting Type
Floor / Wall Mounted

Electrical Control Panel Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
30 Days

Main Domestic Market
All India

About Electrical Control Panel

Featured for their majestic quality and unassailable reliability, our Electrical Control Panels offer a hot deal for industrial and commercial power distribution. Designed with pivotal features like enclosure protection (IP42/IP54 optional), floor or wall mounting, and a Siemens Grey powder-coated finish, these panels ensure safety and durability. Equipped with premium control devices (MCB, MCCB, Contactor, Relay) and built with electrolytic grade copper/aluminium bus bars, they provide superior performance. Available in PCC, MCC, Distribution types, with capacity up to 1000 Amps and customizable sizes, this product is truly a market standout for dealers, distributors, manufacturers, and more across India.

Advantages and Key Features of Electrical Control Panel

Electrical Control Panels serve as pivotal solutions for industrial automation, power distribution, lighting, and process control. Their main advantages include enhanced protection (IP42/IP54), versatile mounting options, and robust construction using mild steel and electrolytic grade copper. The featured machines integrate highly reliable control devices-MCB, MCCB, Contactors, and Relays-making them ideal for safe and efficient electrical management across industries. Used as a central hub, they facilitate optimal power distribution and automation system performance.

Supply Ability and Export Market Insights for Electrical Control Panels

Estimate rapid and flexible supply ability to meet varied project needs, with premium domestic coverage and export market reach. Our panels are designed for standard or custom requirements, guaranteeing consistent availability. As a trusted manufacturer, supplier, and exporter in India's main domestic markets, we ensure hassle-free transactions with flexible payment terms suited to dealer, distributor, and wholesale partners. Experience prompt fulfilment, whether for new installations or large-scale commercial projects.

FAQ's of Electrical Control Panel:

Q: How do I choose the right Electrical Control Panel for my application?

A: Selecting the appropriate control panel depends on factors like power capacity, enclosure protection (IP42 or IP54), type (PCC, MCC, Distribution), and mounting preference. Consider your industrial or commercial requirements and consult our experts for personalized guidance.

Q: What are the key advantages of using this Electrical Control Panel?

A: Our Electrical Control Panels offer advanced safety, customizable sizing, versatile mounting, and robust construction. The integration of premium-grade bus bars and reliable control devices ensures unassailable performance and longevity, making them suitable for diverse automation and distribution needs.

Q: When is enclosure protection IP42 or IP54 recommended?

A: IP42 is recommended for environments where minimal water and dust ingress protection is needed, while IP54 provides enhanced protection for harsher conditions, offering peace of mind in more demanding industrial settings.

Q: Where can these control panels be installed?

A: The panels are suitable for floor or wall mounting in factories, commercial buildings, process plants, and automation centers, adapting seamlessly to both new and retrofit electrical infrastructures.

Q: What is the process for customizing panel size and capacity?

A: Simply share your operational requirements-such as size, capacity, and desired features. Our engineering team will design and fabricate panels tailored precisely to your specifications, ensuring a perfect fit for your power system.
