Three Phase Air Cooled Type

Three Phase Air Cooled Type Specification

Output Current
43 A

Input Voltage
340-460 V

Output Voltage
415 V

Efficiency
Above 98%

Frequency (MHz)
50 Hz

Phase
Three Phase

Current
43 A

Weight
185 kg

Ambient Temperature
-10C to +45C

Degree of Protection
IP20

Control System
Automatic Microcontroller Based

Usage
Industrial, Commercial

Design
Air Cooled

Insulation Resistance
Above 2 M at 500 V DC

Voltage Protection
Over and Under Voltage Protection

Display
Digital Meters

Dimension (L*W*H)
960 x 500 x 1200 mm

Rated Power
30 kVA

Current Type
AC

Waveform Distortion
Nil

Product Type
Three Phase Air Cooled Type Stabilizer

Mounting Type
Floor Mounted

Bypass Arrangement
Manual/Automatic Bypass Available

Regulation
1%

Cooling Method
Forced Air Cooling

Response Time
<20 ms

Enclosure Material
Powder Coated Metal

Operating Humidity
Up to 95% RH, Non-Condensing

Three Phase Air Cooled Type Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
500 Pieces Per Month

Delivery Time
1 Week

Sample Available
Yes

Main Export Market(s)
Asia

Three Phase Air Cooled Type About

Redeem enviable reliability and superlative efficiency with this Three Phase Air Cooled Type voltage stabilizer, featuring the latest forced air cooling design. Highly recommended for industrial and commercial deployment, this valorous unit operates seamlessly at up to 95% RH in non-condensing conditions. Automatic microcontroller-based control delivers swift response time (<20 ms) and admirable regulation (1%), while over and under voltage protection ensures steadfast safety. Boasting a robust powder coated metal enclosure and digital meters, it offers impeccable voltage regulation (415 V) for all your demanding applications. Serving as a manufacturer, supplier, dealer, exporter, retailer, and service provider throughout India.

Versatile Use Across Industrial and Commercial Applications

The Three Phase Air Cooled Type voltage stabilizer is engineered for multi-purpose utility, ideal for both industrial and commercial environments. Primarily used as a voltage stabilizer, it safeguards sensitive equipment and machines by ensuring a constant output voltage. Its application media spans factories, warehouses, large office complexes, and other environments where reliable power quality is critical. This unit guarantees stable performance regardless of fluctuating power inputs, making it a trusted solution for modern operations.

Swift Delivery and Flexible Payment Options Across India

Order processing for the Three Phase Air Cooled Type is prompt, ensuring minimal charge on customer time. Express shipping options are available, delivering across the main domestic market in India. Payment terms are flexible to accommodate business needs, supporting efficient onboarding and reliable after-sales support. Quick dispatch times and streamlined logistics guarantee that your stabilizer reaches your location, enabling seamless integration into your workflow without unnecessary delay.

FAQ's of Three Phase Air Cooled Type:

Q: How does the Three Phase Air Cooled Type voltage stabilizer regulate output voltage?

A: It utilizes an automatic microcontroller-based control system to maintain a steady output voltage of 415 V, despite variations in input voltage, ensuring a 1% regulation and nil waveform distortion.

Q: What are the main benefits of using this stabilizer in industrial or commercial settings?

A: The stabilizer protects sensitive equipment from voltage fluctuations with highly efficient regulation (>98%), quick response time (<20 ms), and robust over and under voltage protection, resulting in reduced downtime and enhanced equipment durability.

Q: When is manual or automatic bypass used in the operation of this stabilizer?

A: The manual or automatic bypass arrangement is employed during maintenance or in emergencies to ensure continuous power supply without disrupting operations, allowing direct current flow when bypassing the stabilizer.

Q: Where can this voltage stabilizer be installed?

A: Designed for floor mounting, it is suitable for installation in industrial plants, commercial buildings, factories, and warehouses-anywhere stable, reliable AC power is crucial.

Q: What is the process for placing an order and receiving this stabilizer in India?

A: Simply contact your preferred producer, supplier, or dealer. Orders are processed efficiently with express shipping available, ensuring quick delivery across India's main domestic market.

Q: How does it handle high humidity operating environments?

A: Built to operate efficiently at humidity levels up to 95% RH (non-condensing), this stabilizer delivers reliable performance even in challenging climate conditions.
