Distribution Panel

Distribution Panel Specification

Base Material
Mild Steel

Protection Class
Class I

Rated Current
Up to 400 A

Thickness
1.6 mm

Connectivity Type
Cable Entry Top/Bottom

Way
4-ways to 18-ways (customizable)

Panel Type
Wall Mounted

Rated Insulation Voltage
690 V

Cover Material
Powder Coated Mild Steel

Control System
Manual Switch

Cooling System
Natural Air Ventilation

Features
Rust Proof, Corrosion Resistant, Sturdy Construction

Current Rating
16 A to 400 A

Operating Voltage
230/415 V AC

Protection Level
IP55

Components
MCB, MCCB, Busbar, Neutral Link, Earth Link

Rated Operation Voltage
415 V AC

Cabinet Material
Mild Steel

Product Type
Distribution Panel

Material
Mild Steel

Surface Finish
Powder Coated

Standard
IEC 61439-1/2

Surface Color
Grey

Rated Voltage
415 V

Frequency (MHz)
50 Hz

Maximum Output Current
400 A

Dimension (L*W*H)
600 x 500 x 200 mm (Standard)

Application
Industrial/Commercial Power Distribution

IP Rating
IP55

Ingress Protection
IP55 Dust & Water Resistant

Short Circuit Withstand Capacity
25 kA for 1 sec

Cable Entry
Knockouts Provided

Conformity
CE Certified

Neutral Bar
Provided

Busbar Material
Electrolytic Grade Copper

Mounting Type
Surface/Wall Mounted

Door Type
Single Door with Lock

Operating Temperature
-10C to +55C

Earth Bar
Provided

Weight
Approx. 22 kg

Distribution Panel Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
30 Days

Distribution Panel About

Experience grand savings and premium access to efficiency with our polished Distribution Panel, the crowning choice for industrial and commercial power distribution needs. Crafted from sturdy, powder-coated mild steel and utilizing electrolytic grade copper busbars, this panel offers reliable surface or wall-mounting, a secure single-door with lock, and customizable way options (4 to 18). With a short circuit withstand of 25 kA for 1 sec and an IP55 rating, it ensures both safety and durability, conforming to IEC 61439-1/2 and CE standards for guaranteed excellence.

Special Features & Versatile Applications

This surface/wall mounted Distribution Panel features state-of-the-art electrical safety with IP55 ingress protection, short circuit withstand capacity of 25 kA, and rust-proof, corrosion-resistant finishing. It is ideally suited for industrial and commercial sites requiring organized, dependable power distribution. It serves as a master point for managing high-capacity current up to 400A, integrating seamlessly with MCBs, MCCBs, and advanced control systems, making it indispensable for professionals seeking advanced power solutions.

Packaging, Payment, and Supply Information

We supply the Distribution Panel with secure packaging, ensuring each unit arrives safe and intact. Transportation is managed efficiently to various destinations across India. Payment terms are flexible to meet your business requirements, and the asking price is highly competitive given the grand quality. The standard FOB port is located in India, reflecting streamlined export and delivery logistics for all dealer, retailer, and wholesaler needs.

FAQ's of Distribution Panel:

Q: How is the Distribution Panel installed at the site?

A: The panel is designed for easy surface or wall mounting. With standard dimensions and knockouts for cable entry, installation can be performed by authorized personnel following IEC 61439-1/2 guidelines.

Q: What are the main benefits of using a Distribution Panel with IP55 protection?

A: IP55 dust and water resistance ensures safe operation in demanding environments, shielding internal components from contaminants and moisture, leading to longer service life and reliable performance.

Q: Where can this Distribution Panel be commonly used?

A: It is well-suited for industrial and commercial sites such as manufacturing plants, commercial complexes, and warehouses where organized and safe power distribution is required.

Q: What makes the busbar material of this Distribution Panel superior?

A: The use of electrolytic grade copper for the busbar guarantees excellent conductivity, reduced power losses, and heightened safety in high-current applications.

Q: How does the advance purchase of this panel result in savings?

A: Advance purchase allows you to lock in competitive pricing, avoid future price increases, and ensures timely access to panels for project scheduling and uninterrupted supply chains.
